本节目标

  • 静态路由
  • 带阴影的椭圆图标
  • 输入有效性校验
  • 组件抽取方法
  • 通用组件、业务组件
  • 程序目录组织
  • 抽取透明导航栏
  • toast 提示组件

视频

代码

https://github.com/ducafecat/flutter_learn_news/releases/tag/v1.0.3

1 静态路由

1.1 定义静态路由

  • 登录页 lib/pages/sign_in/sign_in.dart

  • 注册页 lib/pages/sign_up/sign_up.dart

  • 静态路由 lib/routes.dart

1
2
3
4
5
6
7
8
import 'package:flutter_ducafecat_news/pages/sign_in/sign_in.dart';
import 'package:flutter_ducafecat_news/pages/sign_up/sign_up.dart';

/// 静态路由
var staticRoutes = {
  "/sign-in": (context) => SignInPage(), // 登录
  "/sign-up": (context) => SignUpPage(), // 注册
};

1.2 注册静态路由

  • lib/main.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
import 'package:flutter/material.dart';
import 'package:flutter_ducafecat_news/pages/welcome/welcome.dart';
import 'package:flutter_ducafecat_news/routes.dart';

void main() => runApp(MyApp());

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'ducafecat.tech',
      home: WelcomePage(),
      routes: staticRoutes,
      debugShowCheckedModeBanner: false,
    );
  }
}

2 登录界面

2.1 维护色彩常量

  • lib/common/values/colors.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
import 'dart:ui';

class AppColors {
  /// 主背景 白色
  static const Color primaryBackground = Color.fromARGB(255, 255, 255, 255);

  /// 主文本 灰色
  static const Color primaryText = Color.fromARGB(255, 45, 45, 47);

  /// 主控件-背景 蓝色
  static const Color primaryElement = Color.fromARGB(255, 41, 103, 255);

  /// 主控件-文本 白色
  static const Color primaryElementText = Color.fromARGB(255, 255, 255, 255);

  // *****************************************

  /// 第二种控件-背景色 淡灰色
  static const Color secondaryElement = Color.fromARGB(255, 246, 246, 246);

  /// 第二种控件-文本 浅蓝色
  static const Color secondaryElementText = Color.fromARGB(255, 41, 103, 255);

  // *****************************************

  /// 第三种控件-背景色 石墨色
  static const Color thirdElement = Color.fromARGB(255, 45, 45, 47);
}

2.2 程序结构

  • lib/pages/sign_in/sign_in.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
import 'package:flutter/material.dart';
import 'package:flutter_ducafecat_news/common/utils/utils.dart';
import 'package:flutter_ducafecat_news/common/values/values.dart';
import 'package:flutter_ducafecat_news/common/widgets/widgets.dart';

class SignInPage extends StatefulWidget {
  SignInPage({Key key}) : super(key: key);

  @override
  _SignInPageState createState() => _SignInPageState();
}

class _SignInPageState extends State<SignInPage> {

  // logo
  Widget _buildLogo() {
    return Container();
  }

  // 登录表单
  Widget _buildInputForm() {
    return Container();
  }

  // 第三方登录
  Widget _buildThirdPartyLogin() {
    return Container();
  }

  // 注册按钮
  Widget _buildSignupButton() {
    return Container();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      resizeToAvoidBottomInset: false,
      body: Center(
        child: Column(
          children: <Widget>[
            _buildLogo(),
            _buildInputForm(),
            Spacer(),
            _buildThirdPartyLogin(),
            _buildSignupButton(),
          ],
        ),
      ),
    );
  }
}

2.3 画带阴影的椭圆图标

  • lib/pages/sign_in/sign_in.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
// logo
Widget _buildLogo() {
  return Container(
    width: duSetWidth(110),
    margin: EdgeInsets.only(top: duSetHeight(40 + 44.0)), // 顶部系统栏 44px
    child: Column(
      crossAxisAlignment: CrossAxisAlignment.stretch,
      children: [
        Container(
          height: duSetWidth(76),
          width: duSetWidth(76),
          margin: EdgeInsets.symmetric(horizontal: duSetWidth(15)),
          child: Stack(
            alignment: Alignment.center,
            children: [
              Positioned(
                left: 0,
                top: 0,
                right: 0,
                child: Container(
                  height: duSetWidth(76),
                  decoration: BoxDecoration(
                    color: AppColors.primaryBackground,
                    boxShadow: [
                      Shadows.primaryShadow,
                    ],
                    borderRadius: BorderRadius.all(
                        Radius.circular(duSetWidth(76 * 0.5))), // 父容器的50%
                  ),
                  child: Container(),
                ),
              ),
              Positioned(
                top: duSetWidth(13),
                child: Image.asset(
                  "assets/images/logo.png",
                  fit: BoxFit.none,
                ),
              ),
            ],
          ),
        ),
        Container(
          margin: EdgeInsets.only(top: duSetHeight(15)),
          child: Text(
            "SECTOR",
            textAlign: TextAlign.center,
            style: TextStyle(
              color: AppColors.primaryText,
              fontFamily: "Montserrat",
              fontWeight: FontWeight.w600,
              fontSize: duSetFontSize(24),
              height: 1,
            ),
          ),
        ),
        Text(
          "news",
          textAlign: TextAlign.center,
          style: TextStyle(
            color: AppColors.primaryText,
            fontFamily: "Avenir",
            fontWeight: FontWeight.w400,
            fontSize: duSetFontSize(16),
            height: 1,
          ),
        ),
      ],
    ),
  );
}

2.4 抽取输入框

  • lib/common/widgets/input.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
/// 输入框
Widget inputTextEdit({
  @required TextEditingController controller,
  TextInputType keyboardType = TextInputType.text,
  String hintText,
  bool isPassword = false,
  double marginTop = 15,
}) {
  return Container(
    height: duSetHeight(44),
    margin: EdgeInsets.only(top: duSetHeight(marginTop)),
    decoration: BoxDecoration(
      color: AppColors.secondaryElement,
      borderRadius: Radii.k6pxRadius,
    ),
    child: TextField(
      controller: controller,
      keyboardType: keyboardType,
      decoration: InputDecoration(
        hintText: hintText,
        contentPadding: EdgeInsets.fromLTRB(20, 10, 0, 9),
        border: InputBorder.none,
      ),
      style: TextStyle(
        color: AppColors.primaryText,
        fontFamily: "Avenir",
        fontWeight: FontWeight.w400,
        fontSize: duSetFontSize(18),
      ),
      maxLines: 1,
      autocorrect: false, // 自动纠正
      obscureText: isPassword, // 隐藏输入内容, 密码框
    ),
  );
}

2.5 抽取扁平按钮

  • lib/common/widgets/button.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
/// 扁平圆角按钮
Widget btnFlatButtonWidget({
  @required VoidCallback onPressed,
  double width = 140,
  double height = 44,
  Color gbColor = AppColors.primaryElement,
  String title = "button",
  Color fontColor = AppColors.primaryElementText,
  double fontSize = 18,
  String fontName = "Montserrat",
  FontWeight fontWeight = FontWeight.w400,
}) {
  return Container(
    width: duSetWidth(width),
    height: duSetHeight(height),
    child: FlatButton(
      onPressed: onPressed,
      color: gbColor,
      shape: RoundedRectangleBorder(
        borderRadius: Radii.k6pxRadius,
      ),
      child: Text(
        title,
        textAlign: TextAlign.center,
        style: TextStyle(
          color: fontColor,
          fontFamily: fontName,
          fontWeight: fontWeight,
          fontSize: duSetFontSize(fontSize),
          height: 1,
        ),
      ),
    ),
  );
}

2.6 抽取社交登录按钮

  • lib/common/widgets/button.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
/// 第三方按钮
Widget btnFlatButtonBorderOnlyWidget({
  @required VoidCallback onPressed,
  double width = 88,
  double height = 44,
  String iconFileName,
}) {
  return Container(
    width: duSetWidth(width),
    height: duSetHeight(height),
    child: FlatButton(
      onPressed: onPressed,
      shape: RoundedRectangleBorder(
        side: Borders.primaryBorder,
        borderRadius: Radii.k6pxRadius,
      ),
      child: Image.asset(
        "assets/images/icons-$iconFileName.png",
      ),
    ),
  );
}

2.7 封装 toast 提示框

  • lib/common/widgets/toast.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Future<bool> toastInfo({
  @required String msg,
  Color backgroundColor = Colors.black,
  Color textColor = Colors.white,
}) async {
  return await Fluttertoast.showToast(
    msg: msg,
    toastLength: Toast.LENGTH_SHORT,
    gravity: ToastGravity.TOP,
    timeInSecForIos: 1,
    backgroundColor: backgroundColor,
    textColor: textColor,
    fontSize: duSetFontSize(16),
  );
}

2.8 数据有效性检验

  • lib/pages/sign_in/sign_in.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
...
class _SignInPageState extends State<SignInPage> {

  //email的控制器
  final TextEditingController _emailController = TextEditingController();
  //密码的控制器
  final TextEditingController _passController = TextEditingController();
...

  // 执行登录操作
  _handleSignIn() {
    if (!duIsEmail(_emailController.value.text)) {
      toastInfo(msg: '请正确输入邮件');
      return;
    }
    if (!duCheckStringLength(_passController.value.text, 6)) {
      toastInfo(msg: '密码不能小于6位');
      return;
    }
  }

...

  // 登录表单
  Widget _buildInputForm() {
    return Container(
      width: duSetWidth(295),
      // height: 204,
      margin: EdgeInsets.only(top: duSetHeight(49)),
      child: Column(
        children: [
          // email input
          inputTextEdit(
            controller: _emailController,
            keyboardType: TextInputType.emailAddress,
            hintText: "Email",
            marginTop: 0,
          ),
          // password input
          inputTextEdit(
            controller: _passController,
            keyboardType: TextInputType.visiblePassword,
            hintText: "Password",
            isPassword: true,
          ),

          // 注册、登录 横向布局
          Container(
            height: duSetHeight(44),
            margin: EdgeInsets.only(top: duSetHeight(15)),
            child: Row(
              children: [
                // 注册
                btnFlatButtonWidget(
                  onPressed: _handleNavSignUp,
                  gbColor: AppColors.thirdElement,
                  title: "Sign up",
                ),
                Spacer(),
                // 登录
                btnFlatButtonWidget(
                  onPressed: _handleSignIn,
                  gbColor: AppColors.primaryElement,
                  title: "Sign in",
                ),
              ],
            ),
          ),
          // Spacer(),

          // Fogot password
          Container(
            height: duSetHeight(22),
            margin: EdgeInsets.only(top: duSetHeight(20)),
            child: FlatButton(
              onPressed: () => {},
              child: Text(
                "Fogot password?",
                textAlign: TextAlign.center,
                style: TextStyle(
                  color: AppColors.secondaryElementText,
                  fontFamily: "Avenir",
                  fontWeight: FontWeight.w400,
                  fontSize: duSetFontSize(16),
                  height: 1, // 设置下行高，否则字体下沉
                ),
              ),
            ),
          ),
        ],
      ),
    );
  }

3 注册界面

3.1 程序结构

  • lib/pages/sign_up/sign_up.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
import 'package:flutter/material.dart';
import 'package:flutter_ducafecat_news/common/utils/utils.dart';
import 'package:flutter_ducafecat_news/common/values/values.dart';
import 'package:flutter_ducafecat_news/common/widgets/widgets.dart';

class SignUpPage extends StatefulWidget {
  SignUpPage({Key key}) : super(key: key);

  @override
  _SignUpPageState createState() => _SignUpPageState();
}

class _SignUpPageState extends State<SignUpPage> {

  // logo
  Widget _buildLogo() {
    return Container();
  }

  // 注册表单
  Widget _buildInputForm() {
    return Container();
  }

  // 第三方
  Widget _buildThirdPartyLogin() {
    return Container();
  }

  // 有账号
  Widget _buildHaveAccountButton() {
    return Container();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      resizeToAvoidBottomInset: false,
      ...,
      body: Center(
        child: Column(
          children: <Widget>[
            Divider(height: 1),
            _buildLogo(),
            _buildInputForm(),
            Spacer(),
            _buildThirdPartyLogin(),
            _buildHaveAccountButton(),
          ],
        ),
      ),
    );
  }
}

3.2 透明导航栏

  • lib/common/widgets/app.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
/// 透明背景 AppBar
Widget transparentAppBar({
  @required BuildContext context,
  List<Widget> actions,
}) {
  return AppBar(
    backgroundColor: Colors.transparent,
    elevation: 0,
    title: Text(''),
    leading: IconButton(
      icon: Icon(
        Icons.arrow_back,
        color: AppColors.primaryText,
      ),
      onPressed: () {
        Navigator.pop(context);
      },
    ),
    actions: actions,
  );
}
  • lib/pages/sign_up/sign_up.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
@override
Widget build(BuildContext context) {
  return Scaffold(
    resizeToAvoidBottomInset: false,
    appBar: transparentAppBar(
      context: context,
      actions: <Widget>[
        IconButton(
          icon: Icon(
            Icons.info_outline,
            color: AppColors.primaryText,
          ),
          onPressed: () {
            toastInfo(msg: '这是注册界面');
          },
        )
      ],
    ),

3.2 注册表单

  • lib/pages/sign_up/sign_up.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80

// 注册表单
Widget _buildInputForm() {
  return Container(
    width: duSetWidth(295),
    // height: 204,
    margin: EdgeInsets.only(top: duSetHeight(49)),
    child: Column(
      children: [
        // fullName input
        inputTextEdit(
          controller: _fullnameController,
          keyboardType: TextInputType.text,
          hintText: "Full name",
          marginTop: 0,
        ),
        // email input
        inputTextEdit(
          controller: _emailController,
          keyboardType: TextInputType.emailAddress,
          hintText: "Email",
        ),
        // password input
        inputTextEdit(
          controller: _passController,
          keyboardType: TextInputType.visiblePassword,
          hintText: "Password",
          isPassword: true,
        ),

        // 创建
        Container(
          height: duSetHeight(44),
          margin: EdgeInsets.only(top: duSetHeight(15)),
          child: btnFlatButtonWidget(
            onPressed: () {
              if (!duCheckStringLength(_fullnameController.value.text, 5)) {
                toastInfo(msg: '用户名不能小于5位');
                return;
              }
              if (!duIsEmail(_emailController.value.text)) {
                toastInfo(msg: '请正确输入邮件');
                return;
              }
              if (!duCheckStringLength(_passController.value.text, 6)) {
                toastInfo(msg: '密码不能小于6位');
                return;
              }
              Navigator.pop(context);
            },
            width: 295,
            fontWeight: FontWeight.w600,
            title: "Create an account",
          ),
        ),
        // Spacer(),

        // Fogot password
        Container(
          height: duSetHeight(22),
          margin: EdgeInsets.only(top: duSetHeight(20)),
          child: FlatButton(
            onPressed: _handleSignUp,
            child: Text(
              "Fogot password?",
              textAlign: TextAlign.center,
              style: TextStyle(
                color: AppColors.secondaryElementText,
                fontFamily: "Avenir",
                fontWeight: FontWeight.w400,
                fontSize: duSetFontSize(16),
                height: 1, // 设置下行高，否则字体下沉
              ),
            ),
          ),
        ),
      ],
    ),
  );
}

3.3 检验有效性

  • lib/pages/sign_up/sign_in.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
// 执行注册操作
_handleSignUp() {
  if (!duCheckStringLength(_fullnameController.value.text, 5)) {
    toastInfo(msg: '用户名不能小于5位');
    return;
  }
  if (!duIsEmail(_emailController.value.text)) {
    toastInfo(msg: '请正确输入邮件');
    return;
  }
  if (!duCheckStringLength(_passController.value.text, 6)) {
    toastInfo(msg: '密码不能小于6位');
    return;
  }
  Navigator.pop(context);
}

3.4 社交按钮

  • lib/pages/sign_up/sign_up.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
// 第三方
Widget _buildThirdPartyLogin() {
  return Container(
    width: duSetWidth(295),
    margin: EdgeInsets.only(bottom: duSetHeight(40)),
    child: Column(
      children: <Widget>[
        // title
        Text(
          "Or sign in with social networks",
          textAlign: TextAlign.center,
          style: TextStyle(
            color: AppColors.primaryText,
            fontFamily: "Avenir",
            fontWeight: FontWeight.w400,
            fontSize: duSetFontSize(16),
          ),
        ),
        // 按钮
        Padding(
          padding: EdgeInsets.only(top: duSetHeight(20)),
          child: Row(
            children: <Widget>[
              btnFlatButtonBorderOnlyWidget(
                onPressed: () {},
                width: 88,
                iconFileName: "twitter",
              ),
              Spacer(),
              btnFlatButtonBorderOnlyWidget(
                onPressed: () {},
                width: 88,
                iconFileName: "google",
              ),
              Spacer(),
              btnFlatButtonBorderOnlyWidget(
                onPressed: () {},
                width: 88,
                iconFileName: "facebook",
              ),
            ],
          ),
        ),
      ],
    ),
  );
}

3.5 返回按钮

  • lib/pages/sign_up/sign_up.dart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
// 返回上一页
_handleNavPop() {
  Navigator.pop(context);
}

Widget _buildHaveAccountButton() {
  return Container(
    margin: EdgeInsets.only(bottom: duSetHeight(20)),
    child: btnFlatButtonWidget(
      onPressed: _handleNavPop,
      width: 294,
      gbColor: AppColors.secondaryElement,
      fontColor: AppColors.primaryText,
      title: "I have an account",
      fontWeight: FontWeight.w500,
      fontSize: 16,
    ),
  );
}

蓝湖设计稿

https://lanhuapp.com/url/lYuz1
密码: gSKl

蓝湖现在收费了，所以查看标记还请自己上传 xd 设计稿
商业设计稿文件不好直接分享, 可以加微信联系 ducafecat

参考

视频

© 猫哥

https://ducafecat.tech
